Specifications

QL series lab scale hydrogen generator produce up to 99.9995% purity Hydrogen gas by utilizing SPE technology to electrolyze pure water (no adding alkali).



Specifications of lab scale hydrogen generator:

1. 0~1L/min flow hydrogen generator

2. H2 purity :99.999%

3. PEM technology .

4. CE certification. Own patent right.

Technical Parameter of lab scale hydrogen generator:

Structural characteristics of the Products of lab scale hydrogen generator:

• Distance between anode and cathode is close to zero, and highly active SPE catalytic electrodes are used.
• Plural-electrode and multiunit electrolysis cell structure with excellent chemical technological process properties of the mass and heat transfer.
• Best choice of materials for multi-electrode and pluralist electrolysis cell with excellent properties of electrochemistry, anti-corrosion and bearing deactivation.

Functions and Characteristics of the Products of lab scale hydrogen generator:

• Electrolysis of pure water ( no adding alkali) to produce hydrogen with no corrosion and pollution, and the purity of hydrogen is extremely high.
• Voltage of unit cell is low, and electric resistance in the electrolysis cell is little, giving out no heat, and cycle of changing desiccants is long, producing highly pure hydrogen.
• With stable pressure and output, Hydrogen is controlled according to the requirements, and automatic control technology is perfect and reliable.
• Power consumption is less, and the electrolysis is efficient.

Applied Area of lab scale hydrogen generator:

• The small-sized products (QL-150/300/500/1000) are ideal equipment for gas chromatographs and optical fiber sintering. The products can absolutely take the place of steel cylinders of hydrogen, and can be used safely and conveniently.
• Used for fuel cell.
• Supply hydrogen for metal hydride.
• Others application: reduction protection ,purification of materials , Metal welding and smelting, fire fiber optic, surface protection , Used for cars or truck.
• storing power for wind power, solar power generator ,Etc
